John Deere 4010 wiring diagram?



Post new topic
View previous topic :: View next topic
Author Message
NoelC
New User


Joined: 30 Jun 2013
Posts: 15
Location: NM

Report to Moderator

PostPosted: Sat Aug 29, 2015 5:49 am    Post subject: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

Does anybody happen to know where I can find a wiring diagram for a 4010? Can't get it
to turn over. Tested the starter, replaced the solenoid, replaced the ignition switch,
Checked the batteries. Suspect it must be a wiring problem.

Back to top
View user's profile
buickanddeere
Tractor Guru


Joined: 31 May 2003
Posts: 33909
Location: in front of computer

Report to Moderator

PostPosted: Sat Aug 29, 2015 7:26 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote


Given that the tractor is approaching 55 years old. It's time to consider that the old wiring harness is "done". Age, vibration, exposure to dust, dirt, mud, manure, oil, vibration and rodents have taken their toll.
I have used http://www.wiringharnesses.com/ and they are the best value for the $$$.
Better than having a tractor that won't start or bursts into flame.
This would also be the time to consider the 12V conversion.

Back to top
View user's profile
Tx Jim
Tractor Guru


Joined: 14 Feb 1999
Posts: 27213
Location: Coyote Flats

Report to Moderator

PostPosted: Sat Aug 29, 2015 8:29 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote


I'd suggest to check operation or lack of the neutral start switch(parts key 12) under cowling in frt of gearshift control lever


Back to top
View user's profile
coonie minnie
Tractor Expert


Joined: 03 Feb 2013
Posts: 2837


Report to Moderator

PostPosted: Sat Aug 29, 2015 9:09 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

I would suggest you check the function of the neutral start switch.... and that the harness is atatched to it. Look behind the right hand battery.

Back to top
View user's profile
coonie minnie
Tractor Expert


Joined: 03 Feb 2013
Posts: 2837


Report to Moderator

PostPosted: Sat Aug 29, 2015 9:11 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

And it looks like Jim beat me to the answer. It's behind the battery on a 4020... not sure on the 4010. I assumed the same.

Back to top
View user's profile
NoelC
New User


Joined: 30 Jun 2013
Posts: 15
Location: NM

Report to Moderator

PostPosted: Sat Aug 29, 2015 9:19 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

My father's tractor, I'm relaying messages to him. He doesn't think it has a neutral start switch, it used to turn over while in gear, had a 4020 with one. I'll tell him where to look.

Back to top
View user's profile
Tx Jim
Tractor Guru


Joined: 14 Feb 1999
Posts: 27213
Location: Coyote Flats

Report to Moderator

PostPosted: Sat Aug 29, 2015 9:27 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote


Check all 4 battery post connections for cleanliness & tightness.

Back to top
View user's profile
NoelC
New User


Joined: 30 Jun 2013
Posts: 15
Location: NM

Report to Moderator

PostPosted: Sat Aug 29, 2015 9:35 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

He has. Took the batteries out, charged one, replaced the other with a new one.

Back to top
View user's profile
buickanddeere
Tractor Guru


Joined: 31 May 2003
Posts: 33909
Location: in front of computer

Report to Moderator

PostPosted: Sun Aug 30, 2015 4:46 pm    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote


Mis-matched batteries can be a factor causing battery explosions.

Back to top
View user's profile
Tx Jim
Tractor Guru


Joined: 14 Feb 1999
Posts: 27213
Location: Coyote Flats

Report to Moderator

PostPosted: Mon Aug 31, 2015 2:39 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

buickanddeere wrote:
(quoted from post at 19:46:57 08/30/15)
Mis-matched batteries can be a factor causing battery explosions.


b&d
Please explain your "mis-matched" battery theory??

I've always heard in 24 volt system that new 12 volt batt installed with old 12 volt would draw new battery output down to equal old battery output but I never witnessed any explode except where "internal or external sparks" existed.

Back to top
View user's profile
buickanddeere
Tractor Guru


Joined: 31 May 2003
Posts: 33909
Location: in front of computer

Report to Moderator

PostPosted: Mon Aug 31, 2015 6:10 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

Tx Jim wrote:
(quoted from post at 06:39:17 08/31/15)
buickanddeere wrote:
(quoted from post at 19:46:57 08/30/15)
Mis-matched batteries can be a factor causing battery explosions.


b&d
Please explain your "mis-matched" battery theory??

I've always heard in 24 volt system that new 12 volt batt installed with old 12 volt would draw new battery output down to equal old battery output but I never witnessed any explode except where "internal or external sparks" existed.


It's not a theory . The stronger battery can push the weakest cell on the weak battery into reversal. That causes boiling and gassing vast amounts of hydrogen and oxygen. Add ignition source such as a failing internal link in the battery and BOOM.

Back to top
View user's profile
Tx Jim
Tractor Guru


Joined: 14 Feb 1999
Posts: 27213
Location: Coyote Flats

Report to Moderator

PostPosted: Mon Aug 31, 2015 8:16 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

buickanddeere wrote:
(quoted from post at 09:10:21


It's not a theory . The stronger battery can push the weakest cell on the weak battery into reversal. That causes boiling and gassing vast amounts of hydrogen and oxygen. Add ignition source such as a failing internal link in the battery and BOOM.


Failing internal link in a battery will cause a ""BOOM"" without the aid of a new battery attached to it.

Back to top
View user's profile
Mike Aylward
Tractor Guru


Joined: 24 Feb 1999
Posts: 5241


Report to Moderator

PostPosted: Mon Aug 31, 2015 8:28 am    Post subject: Re: John Deere 4010 wiring diagram? Reply to specific post Reply with quote

On a 4010 the neutral safety start switch is just ahead of the shifter assembly under the right hand side of the dash cowling. Mike

Back to top
View user's profile
:
